Prix : 5 890 € - sans capot
Disponibilité : sur commande (me contacter pour le délai)
Présentation
Caractéristiques techniques
| Turntable Platter | |
| Drive system | Belt drive system |
| Motor | Brushless DC motor with PID control |
| Material | Machined aluminum, Surface finish / Diamond cut |
| Revolution | 33 1/3rpm, 45rpm, 78rpm (3 speeds selectable) |
| Revolution adjustment range | ±6% (each rotation speed adjustable independently) |
| Wow and flutter | 0,04% or less (W.R.M.S.) |
| Weight (Platter) | 4,0 kg |
| Tone arm section | |
| Type | Static balanced, S shaped, universal type |
| Bearing | Concealed knife edge |
| Effective length | 222.5mm |
| Overhang | 18mm |
| Tracking error angle | ±3° or less |
| Applicable cartridge weight | 4 to 10g (including headshell 17 to 23g) |
| Adjustable height range | 15mm |
| Anti-skating | 0 to 4g |
| Main unit | |
| Power source | 230V~50Hz / 115V~60Hz |
| Power consumption | 6W |
| Dimensions | 465 (W) x 133 (to the upper surface of platter) (H) x 393(D) mm |
| Net weight | 15,8 kg (main unit), 17,2kg (with dust cover) |
| Accessories | Platter, Headshell, Ruber mat, Rubber belt, Platter mount handle (2 pieces), EP adaptor, |
| Counterweight, Arm adjustment hex wrench set (2 types), | |
| Flathead screwdriver for rotation speed adjustment phono cable (DIN >> RCA | already installed on the unit), Power cable |
